CNC BEYELER EURO II PS 150/4100 press brake

CNC BEYELER EURO II PS 150/4100 press brake was built in Switzerland in 1993. The machine allows bending 4100 mm long elements with a maximum pressure of 150 t. Numerical control CYBELEC EURO II, which allows you to program 3 axes.

Technical parameters of the BEYELER EURO II PS 150T X 4100 MM CNC press

– CNC control: CYBELEC EURO II
– pressure: 150 t
– working length: 4100 mm
– work, 3 axes: Y1, Y2, X
– die, 4 grooves: 50, 35, 22, 16 mm (for sheet thicknesses from 6 to 1 mm)
– punches, sections: 170, 200, 345, 920 and 2 x 1000 mm each
– machine drive CNC BEYELER EURO II PS 150/4100: 11 kW
– dimensions (width x depth x height): 4.65 x 1.40 x 2.65 m
– weight of the press: 11 tons
