MEP COBRA 350 AX automatic circular sawing machine

MEP COBRA 350 AX automatic circular sawing machine was built in Italy by MEP SpA. The machine, designed for cutting workpieces at an angle of 90° and 45°, is distinguished by its high productivity and precision. The machining process is performed automatically or manually by means of a cutting disc with a diameter of 350 mm. The cutting disc is continuously lubricated and cooled to increase operational reliability. The MEP COBRA 350 NC AX circular sawing machine weighs approximately 560 kg.

Technical specifications of the MEP COBRA 350 AX metal circular sawing machine

• cutting angle: 90°; 45°
• cutting capacity (90°, circle): 105 mm
• cutting capacity (90°, rectangular section): 180×70 mm
• cutting capacity (45° to the left, square section): 95 mm
• cutting capacity (45° to the left, rectangular section): 135×60 mm
• cutting capacity (45° to the right, circle): 110 mm
• cutting capacity (45° to the right, square section): 95 mm
• cutting capacity (45° to the right, rectangular section): 135×60 mm
• cutting disc diameter: 350 mm
• cutting disc bore diameter: 32 mm
• automatic lubrication and cooling of cutting disc
• operation mode: manual or automatic
• pneumatic feeder
• roller conveyor 5 m
• total power requirement: 2.29 kW
• dimensions (L x W x H): approx. 2720 x 1460 x 1740 mm
• weight of the machine: approx. 560 kg
